BASH Logo Ballistic Anti-Shock Housing

BASH IP68 Camera Housing

Professional camera armor for all mobile, marine, and security video applications with IP68 protection. Designed for all mini-dome, megapixel, micro PTZ, HD, and specialty cameras.

The BASH All-Pro with PoE now comes with Dual Power Mode! Passive PoE or Vehicle based 12VDC for Maximum Versatility.

BASH™ (Ballistic Anti-Shock Housing) is the first of its kind providing the ultimate mobilized security protection for your camera. BASH™ was designed to withstand anything that this world can throw at it, literally. BASH’s strength comes from it’s High Impact Lenses and with the optional Armored Reflective Lens you can both hide and protect the equipment inside. It has a unique 12 point floating stabilization system called Shell-Shock Vibration Suppression. It’s compact design mounts and looks just like any mountable auxiliary truck light. The Thermal Temperature Control creates a barrier for your camera that fights against temperature changes from -40 degrees F all the way up to 167 degrees F while allowing the camera inside to operate at its desired temperature. With an IP68 rating, BASH™ can withstand up to 2 meters (6.5′) of water. Its IK10 vandal/anti-theft rating is the maximum security protection and can only be found with BASH™. BASH™ is also multi-camera ready supporting GoPro’s, Low Profile PTZ’s, and Minidome cameras. This system is network and video recording ready to provide the highest level of accessibility from anywhere in the world. BASH’s unique design makes its applications limitless with uses such as boating, commercial fleets, construction crews, utility vehicles, trucks, semi-trucks, utility poles, bridges, ATV’s, snow mobiles, police, emergency vehicles, fire and rescue, border patrol, and so much more.

BASH Camera Compatibility Guide

BASH™ enclosures work with all cameras up to 3.9 inches tall and 5.5 inches in diameter (most minidome cams). Download the BASH Camera Compatibility Guide for model details.

2015-bash-camera-compatibility-guide-by-dotworkz-camera-height-of-up-to-4-inches

2015-bash-camera-compatibility-guide-by-dotworkz-2-up

2015-bash-camera-compatibility-guide-by-dotworkz-camera-diameter-of-up-to-5-and-a-half-inches

BASH™ enclosures work with cameras and camera brands such as: Minidome, Micro PTZ, Wide Angle, Wide Dynamic Range, Megapixel, Axis, Avigilon, Sony, GoPro, Sony Action Cam, Canon, Panasonic, Arecont, Samsung, D-Link, ACTi, and more.

BASH Camera Enclosure With Lens Options For Every Application

BASH Camera Enclosure With Compatible Camera Options For Every Application 1280 Wide Short

BASH Wins New Product Showcase

BASH Wins Best Video Surveillance Hardware and Accessories of the Year at ISC West 2015

dotworkz 2015 bash wins new product showcase bash all-pro shown with award

dotworkz 2015 bash wins new product showcase award shown narrow

dotworkz 2015 bash wins new product showcase bash original shown with award

Dotworkz the King of Action Camera Housings

Dotworkz the King of Action Camera Housings

3 Models to choose from:

((BASH))™ Original

bash product front view cut out with camera dotworkz 2015 real products bash og original

BASH™ Original Model Includes:
Model #: BASH-OG

• Clear High Impact lens system
• Force 10 Adjustable Camera Bracket with lock out
• Type III Hard Anodized 6061-T6 Aluminum
• Heat Resistant Thermoplastic Shell
• 12 point Shell Shock Vibration Suppression
• IP68 Waterproof
• Uni-Directional Passive Cooling via Thermal Cooling Disk™
• Optional Vandal Proof Stainless Steel Hardware Pack
• Optional Metalized (Mirrored) High Impact lens system
• Optional Ballistic Impact lens system

Suggested/Compatible Cameras:

• Small Form DSLR Cameras
• IP/Network Cameras
• Micro Dome Cameras
• 180 Degree Cameras
• Dropcam Cameras

((BASH))™ G-Pro

bash product front view cut out with camera dotworkz 2015 real products g pro

BASH™ G-Pro Includes:
Model #: BASH-GPRO

• GoPro Specific Power Harness
• Built-in Exterior Mounted Water Proof Microphone
• 12VDC to 5VDC Continuous Power Management
• Clear High Impact Lens System
• Force 10 Adjustable Camera Bracket with Lock Out
• Type III Hard Anodized 6061-T6 Aluminum
• Heat resistant Thermoplastic Shell
• 12 point Shell Shock Vibration Suppression
• IP68 Waterproof
• Uni-Directional Active Cooling via Solid State Thermal Cooling Disk™
• Optional Vandal Proof Stainless Steel Hardware Pack
• Optional Metalized (Mirrored) High Impact lens system
• Optional Ballistic Impact lens system

Suggested/Compatible Cameras:

((BASH))™ All-Pro PoE

bash product front view cut out with camera dotworkz 2015 real products all pro

Now with Dual Power Mode! Passive PoE or Vehicle based 12VDC for Maximum Versatility.

BASH™ All-Pro with PoE Includes:
Model #: BASH-HB-POE

• 1 Clear High Impact Lens System
• Plus 1 Tinted High Impact Dome (“bubble type”) Lens
• Built-in Exterior Mounted Water Proof Microphone
• PoE or 12VDC Powered Heater Blower Providing PoE to Camera
• Dual Power Mode – Passive PoE for 30 watts + or 12VDC wall or battery
• Continuous Power Management
• Force 10 Adjustable Camera Bracket with Lock Out
• Optional Vandal Proof Stainless Steel Hardware Pack
• Type III Hard Anodized 6061-T6 Aluminum
• Heat resistant Thermoplastic Shell
• 12 point Shell Shock Vibration Suppression
• IP68 Waterproof
• Uni-Directional Passive Cooling via Solid State Thermal Cooling Disk™
• Optional Vandal Proof Stainless Steel Hardware Pack
• Optional Metalized (Mirrored) High Impact lens system
• Optional Ballistic Impact lens system

Suggested/Compatible Cameras:

• Small Form DSLR Cameras
• Mini Dome Cameras
• 180 Degree Cameras
• 360 Degree Cameras
• Mini PTZ Cameras
• PoE IP Cameras
• Specialty Cameras

BASH G-Pro Tips:

Driving Innovation with Simply the BEST Mobile and Outdoor Video Housings.

BASH G-Pro Tip #1
Did you know the BASH supplies power to keep your Gopro charged and always on.

BASH G-Pro Tip #2
Use your BASH to turn your GoPro into a live monitoring or security feature on your vehicle or boat.

BASH G-Pro Tip #3
The BASH is likely the most protection a small camera can get? water, ice, heat, vibration, bullets and even theft.

BASH G-Pro Tip #4
With the Built in microphone the BASH is not only the best for vehicle mounted GoPro video but it can record clear audio even when driving or boating.

BASH Accessories

  • bash 2015 accessory vandal proof hardware pack for bash featured image new

    Vandal Proof Hardware Pack for BASH

    The Vandal Proof Hardware Pack is great hardware accessory making BASH™ virtually theft-proof. Requiring a special tool pack, this BASH™ accessory will detour all vandals. The Vandal Proof Hardware Pack for BASH™ is very easy to use and installs in minutes.
    Learn more | Buy Now

  • bash 2015 accessory ir illuminator front down angled featured image

    IR Illuminator for BASH

    The IR Illuminator is great lighting accessory for BASH™ providing an abundance of light. Requiring very little power makes this light addition a must have BASH™ accessory for poorly lit areas. The IR Illuminator for BASH™ is very easy to install with only 4 bolts required for internal mounting.
    Learn more

  • bash accessory ballistic lens with bullet tested lens mounted new featured image

    Ballistic Lens for BASH

    The Ballistics Lens for the BASH security camera enclosure is level 1 rated bullet proof. This level provides bulletproof protection against small arms fire such as 9mm. This lens is 3/4 inch thick and layered with 3 types bullet proofing polycarbonates. There is minimal reduction in visibility making this lens the perfect solution for taking your current or next security system to the next level.
    Learn more | Buy Now

dotworkz housings bash multi viewing array real products

dotworkz housings bash multi viewing optoins array mobile real products

Ultra Compact Design

Engineered to look great on Trucks, Cars, and Boats

dotworkz housings bash by dotworkz size comparrison new

Easy to Install

bash 2015 actual product small all pro front angle

Front Ring and Back Panel Color Options

BASH Product Ring Color Options

B Lock Mount for Every Application

B Lock - Mount for BASH by Dotworkz (3 Views)

Armored Reflective Lens - BASH FeaturesArmored Reflective Lens
(Protects & Hides Your Camera)

Shell Shock Vibration Suspension - BASH FeaturesShell-Shock Vibration Suppression
(12 Point Floating Stabilization System)

Compact Design - BASH FeaturesCompact 7.5” Diameter
(Looks & Mounts Like an Auxiliary Truck Light)

Thermal Temperature Control - BASH FeaturesThermal Temperature Controlled
(Climate protection from -40⁰ F to 167⁰ F)

IP68 (Up to 2 meters of water protection) - BASH FeaturesIP68
(100% Water Tight Up To 2 Meters)

IK10 Anti-theft and Vandal Proof - BASH FeaturesIK10 – Vandal/Anti-Theft
(Maximum Security Protection Only With BASH™)

Multi Camera PTZ Mminidomes Ready - BASH FeaturesMulti Camera Compatibility
(Go Pros, Low Profile PTZs, & Minidomes)

Network and Video Recording Ready - BASH FeaturesNetwork & Recording Ready
(Wireless & Data Storage Options)

Limitless Applications - BASH FeaturesLimitless Applications
(Boats, Fleets, Trucks, Semi-Trucks, Utility Poles, Bridges, Mobile, ATVs, Police, Rescue, Border Patrol, & More)

 Shell-Shock Vibration Suppression

BASH with the 12 point floating stabilization system called Shell-Shock Vibration Suppression System

Made in the USA

Why buy from the Official Dotworkz Online Store

IP68, Mil spec, & UL listed.

BASH Product - Multi-Camera PTZ Minidome Ready

Popular Compatible Cameras for BASH™

bash 2015 popular compatible cameras gopro hero

GoPro Hero 4

bash 2015 popular compatible cameras black magic micro studio camera 4k ultra high definition

Blackmagic Micro Studio Camera 4K

bash 2015 popular compatible cameras sony action cam

Sony Action Cam

bash 2015 popular compatible cameras garmin virb x and xe

Garmin VIRB Action Camera X & XE

bash 2015 popular compatible cameras axis p3367 mini dome

Axis P3367 Mini Dome Camera

bash 2015 popular compatible cameras axis m1014 drop cam

Axis M1014 Drop Cam

Customize your BASH™ with our OEM Team

Special Order/OEM Examples – Call our OEM & Specialty Projects Team at (866) 575-4689

BASH™ Special Order “White” or Clear Anodized Front Ring

bash product front view cut out with camera dotworkz 2015 real products special order front ring paintable anodizable clear ring

BASH™ Special Order Blue Anodized Front Ring

bash product front view cut out with camera dotworkz 2015 real products special order front ring paintable anodizable blue anodized

BASH™ Special Order Forest Army Camouflage Painted Front Ring

bash product front view cut out with camera dotworkz 2015 real products special order front ring paintable anodizable army green camouflage

BASH™ Special Order Desert Army Camouflage Painted Front Ring

bash product front view cut out with camera dotworkz 2015 real products special order front ring paintable anodizable army desert camouflage

Mount It Anywhere

B-Lock – BASH™ Mount by Dotworkz

1.5″ – 2.25″ diameter bumper mount for easy no drill installation. Engineered for provide the ultimate protection against Vandalism/Theft. The B-Lock is designed to mount on any bar of roof rack system. Compatible mounting options include: Yakima, Thule, Car Racks, Roof Racks, Roof Rack Systems, Light Bars, Light Bar Systems, Roll Cages, and Chain Link Fence Poles.

B Lock - Mount for BASH by Dotworkz (Kit)

B Lock - Mount for BASH by Dotworkz (Side View) Size Reference

dotworkz housings bash multi viewing array with b lock mount by dotworkz real products

dotworkz housings bash multi viewing array with b lock mount by dotworkz mobile real products

BASH Logo Ballistic Anti-Shock Housing

Engineered for Vibration Resistance

Anti-Vibration Shell Shock System with 12 Point Vibration Suppression (Patent Pending)

bash 2015 anti vibration 12 point suspension by dotworkz real product photo

BASH Logo Ballistic Anti-Shock Housing

Vehicle Ready - Border Patrol Tough

Integrated extreme outdoor microphone

bash 2015 actual product small all-pro front angled view

BASH-Logo-2015-Ballistic-Anti-Shock-Housing-White-with-TM-Desert-Dots

Marine/Boat Ready - IP68 Ultimate Water and Anti-Corrosion Protection

Water Proof
Chemical/Salt Resistant

Dotworkz BASH Side View Back White

BASH Logo Ballistic Anti-Shock Housing

Military Grade - Engineered for Extreme Protection

Vibration Resistant per Mil spec (MIL-STD-810G)

bash 2015 actual product small all-pro front angled view

BASH-Logo-2015-Ballistic-Anti-Shock-Housing-White-with-TM-Desert-Dots

Ultra Compact Design

Waterproof IP68 with Audio
Passive and Active Cooling Options*

*Patent Pending

bash 2015 actual product small g-pro front angled view

BASH™ Applications

Video Mobilize Your…

Fun, Fleets, Construction Crew, Trucks, City Projects, Police, Rescue, Border Patrol, & More

New for 2017: BASH Camera Housings for Self Driving Vehicles, Fence Lines, Entrance Ways, and more!

Marine

Off Road Trucks

ATV

Bridges

Utility Poles

BASH Unlimited Applications - Fence Mounted Example

Border Patrol

Police

Emergency Vehicles

Commercial Fleets

Utility Vehicles

Construction Crews

IP68

100% Water Tight Up To 2 Meters

IP68 Means Real World Longevity
What IP68 means to you: With a Dotworkz IP68 housing you get the ultimate protection for your security camera and security camera equipment keeping dust, debris, insects, and water outside the enclosure.

BASH - IP68 Underwater Test

Simply Uncompromising

When we say extreme we mean it with our no compromise IP68 seal.

Protection That Lasts

Product Guide

The Dotworkz product line is optimized for a wide range of video cameras including all powerful Pan Tilt and Zoom (PTZ), mini dome, fixed, static, IP, as well as the latest HD/Megapixel network cameras.

BASH

D Series by Dotworkz

S-Type by Dotworkz

Accessories by Dotworkz

OEM Dotworkz

Original OEM parts by Dotworkz

Build your next security housing system with Dotworkz OEM

OEM Dotworkz

Get your product to your market faster!

At Dotworkz we are recognized as a leader in OEM.
Find out how you can join our program!

Dotworkz 2016 BASH The Gold Standard
